• APET-PETG-CPET-PLA Sheet Product Line
  • APET-PETG-CPET-PLA Sheet Product Line

TYPE:

NAME:Single and Multi layer APET/PETG/CPET/PLA Plastic Sheet Extrusion Equipment

Single and Multi-layer APET/PETG/CEPT/PET Sheet Extrusion Equipment

Benk Machinery Co LTD‘s Single and Multi layer APET/PETG/CPET/PLA plastic sheet extrusion equipment: This is the production line widely used throughout China and worldwide with the matured technology and the stable production ability. It has high capacity, high precision, and lower electric consumption features. It has the unique mode of “key to acceleration” that can realize low-speed adjustment, high-speed production without fluctuation along with high stability.

PLA sheet production line.
PLA is a renewable biodegradable material. PLA sheet can be used in rigid packages of vegetables, fruits, eggs, and baked goods, also can be used for some other packages like a fresh flower.

PETG sheet

PETG is called low-temperature PET, it’s a new environment-friendly packing material with features such as high luster, good transparency, excellent barrier property, self-adhesion, which is used for glue bonding and high-frequency processing.

CPET sheet

CPET is a kind of modified PET. With good resistance to high temperature, it is usually used for a package in a microwave oven.

PET stereoscopic optical grating sheet

It can be used as top-grade package for cosmetics, medicine, tobacco & alcohol and common goods such as stationery,

advertisements, posters and all kinds of cards.

PLA sheet

PLA is a kind of line shape Aliphatic Polyesters. PLA can be used in a rigid package of fruits, vegetables, eggs, cooked food and

roast food also can be used for packaging of sandwiches, biscuit,s and some other packages like a fresh flower.

Products application:

It has the features of good processing capacity, transparency, innocuity, no smell and no pollution, easy in recycling.

Vacuum Forming:

Food packing, toy box, stationery cases, tools and hardware packing.

Obstruct application:

Electron components packing.

Normal application:

Fold forming, under the collar, decorate material, file folder, paper file, documents cover, credit cards.

Special application:

Medical equipment, medicine packing, industrial antisepsis, plate for microwave oven. (CPET)



APET/PETG/CPET/PLA Single or Multi-layer Sheet Production Line Main Technical Specification

Model CHD-75/85/95 CHD-120/90/65
Material APET, PETG, CPET APET, PETG, CPET
Width 650 mm-1550 mm 650 mm-1550 mm
Thickness 0.08 mm-2.5 mm 0.13-2.5 mm
Extruder Φ75/Φ85/Φ95 Φ120/Φ90/Φ65
Capacity 550-1200 kg/h 450-600 kg/h
